Available for hire or purchase
2 Standard Models:
Model C36 belt widths up to 1000 mm (36”)
Model C72 belt widths up to 1800 mm (72”)
Both models can reel up to approx 200 metres of 12.5 mm (1/2”) thick belt.
Portable for ease of handling on site and available with diesel or electric drive. Can be transported by 35cwt pick-up truck.
Hired extensively to British Coal and numerous quarries throughout the UK. Incorporating the unique ‘Roll Releasing Mechanism’.,
Technical Information
Overall weight of C72 - 1.5 tonnes
Lister Diesel Engine ST2 15 bhp and clutch driving via vee belts to Radicon worm reduction gearbox.
INDIVIDUAL MACHINES FOR ALTERNATIVE SIZES AND SPECIFICATION MADE TO ORDER.
.............................................................................................................................................................................................
Belt Cutting Machines
The Canning Belt Cutting Machine is a most economical , cost effective way of cutting conveyor belting. Models / Sizes to suit application available with diesel or electric drives.
INDIVIDUAL BELT CUTTING MACHINES ARE MADE TO ORDER TO SUIT REQUIREMENTS/SPECIFICATIONS.
Contact our engineering department for further details.’
