MATERIAL : CARBON STEEL
BELLOWS : 2 DOUBLE BELLOW NEOPRENE-HYPALON® 60 30
CONES : SMALL CONES 30 60
STROKE MT : STROKE 3 MT
STROKE MM : STROKE 0 MM
FEEDING : DRIVE CAT 3D ATEX
MOTORISATION : 220-240 V 50 HZ ---380-420 V 50 HZ
LEVEL INDICATOR : DOUBLE ROTARY LEVEL INDICATOR 24 VOLT ATEX
ANTIWASTE DEVICE : WITHOUT BOTTOM CLOSURE CONE
CONTROL PANEL : ELECTRIC PANEL AND PUSHBUTTON PANEL ATEX
CARTRIDGES : ANTISTATIC CARTRIDGES
EXTENDED : 4970.0 MM
RETRACTED : 2240.0 MM
WEIGHT : 326.0 KG
INLET DIAMETER : 300.0 MM
MAXIMUM CAPACITY : 250.0 M3h
PACKAGING : 1200.0 X 1300 X 1900
ATEX COMPLIANT : . GR.II CAT 3D C T185 C - MIE 3MJ - TAMB -20 C +40 C
PAINTING : 3003D OUTSIDE RAL 5010
ASKING PRICE GBP£8000.00 ex works Worksop, Nottingham UK
Delivery: Ex Stock
**CONTACT OUR ENGINEERING DEPARTMENT on +44 1909 486166 or email sales@canningconveyor.co.uk
